1-Wire Distribution Box (8× RJ45)
The distribution box enables a 1:1 pass-through connection of eight 3-wire cables. Ideal for building star-topology 1-Wire installations. The shielded RJ45 sockets are 8-pin and wired 1:1. Two mounting holes on the back allow wall mounting.
Specifications
| Property | Value |
|---|---|
| Order code | 3000793 |
| Connections | 8× RJ45 (shielded, 8-pin, 1:1) |
| Cable topology | Star |
| Protection rating | IP20 (EN 60529) |
| Dimensions (L × W × H) | 94 × 55 × 28 mm |
| Temperature range | 0 °C to +50 °C |
| Humidity | 10–92 % RH (non-condensing) |
Compatible Products
- Gateway V4 + Temperature — 1-Wire star topology via RJ45
Ordering
Contact sales@lobaro.de for ordering information.
